PI 590-1 Digital Process Indicator
| Business Type | Manufacturer, Exporter |
| Country of Origin | India |
| Type | Automatic |
| Shape | Rectangle |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
Voltage
220V
Finishing
Polished
Warranty
1 Year
Brand Name
SANSEL
Features :
- 16 Characters LCD Display
- mV / mA / Volt Analog Inputs
- Wide Input Ranges ± 75mV / ± 10V
- Wide Display Ranges - 199999 to +199999
- Parameter & Unit Display User Front Configurable
- 2 Relay Outputs with Configurable H / L Setting(Optional)
- Re Transmission Output (Optional)
- 24 V DC Sensor Supply
- Universal Supply Voltage 90 to 270V AC / DC
Specifications
| Model | PI 590-1 |
| Input | : -75 to +75mV / 0 to +20mA / -10 to + 10V ( programmable Input Lo & Hi Limits) |
| Range | -199999 to +199999 (programmable Range Lo & Hi Limits) |
| Resolution | 0.00001 / 0.0001 / 0.001 / 0.01 / 0.1 / 1 (selectable) |
| Accuracy | ± 0.1% of FS / ± 0.05 % of FS |
| Display | 16 Character x 2 Line LCD |
| Relay Output (Optional) | 2 NO , 2 COM 5 A Rated Relay with individual H / L set |
| Re transmission Output | |
| (Optional) | 4 - 20 mA (or) 0 - 10V DC (Factory Selectable) |
| Sensor Supply | 24 V DC / 100 mA |
| Working temperature | 0 - 50 ºC |
| Power Supply | 90 to 270V AC / DC 50Hz |
| Dimension | 96 x 96 x 65 mm. |
| Weight | 200 grams (Approx.) |
